System Interface

Data transfer speed

Max. 150 MB/s

Performance

CD

Key: insert "Max X" speed for each media below. For CD 1X=150 KB/s; DVD 1X=1350 KB/s; BD 1x = 4.5 MB/s

Read

Max.24X

Digital Audio Extraction (DAE)

Max.20X

Write CD-R

Max.16X

Write CD-RW

Max.10X

DVD

Read (Single Layer / Dual or Double Layer)

Max. 8X/6X

Write DVD+R Double Layer

Max.2.4X

Write DVD-RAM

Max.5X

Write DVD+RW

Max.4X

Write DVD-RW

Max.4X

Power Consumption

Typical

1100 mA

Acoustic noise

Operating (Sound pressure level, typical)

less than 50 dBA

Power supply

Voltage

DC5V +/-0.25V

Temperature

Operating C (F)

5 ~ 50 C (41 ~ 122 F)

Non-operating C (F)

-40 ~ 65 C (-40 ~ 149F)

Relative Humidity

Operating (No condensation)

10 ~ 90%

Non-operating (No condensation, Power Off, without disc)

 5 ~ 95%

Altitude

Operating m (ft)

-200m ~ 3,048m (-656 ~ 10000ft)

MTBF:

60,000h (Duty:20%)

Dimensions and weight

Width mm (in)

128 mm (5.04 in)

Depth mm (in)

129.0 mm (5.08 in)

Height mm (in)

9.5 mm (0.37 in)

Weight g

140g +/-10g
